Varex LumenHD DR Systems
The Varex Pedigree
Varex Imaging brings more than 75 years of X-ray imaging heritage, with roots in Varian Associates and decades of experience developing the core technologies behind diagnostic imaging systems. Varex began producing X-ray tubes in 1970 and flat-panel detectors in 1999, and became an independent imaging company when it was spun out of Varian Medical Systems in 2017. Its detector expertise was further strengthened through the acquisition of PerkinElmer’s Medical Imaging business, adding additional flat-panel and CMOS detector technology to an already extensive imaging portfolio. Today, Varex components—including X-ray tubes, detectors, high-voltage components and imaging software—are incorporated into imaging systems produced by OEMs around the world.
The Evolution to LUMEN HD
The LUMEN HD represents the latest evolution of that detector experience. The original LUMEN 4336W, introduced in 2021, was designed around flexibility and serviceability, with common hardware supporting wireless or tethered operation and shared accessories across the LUMEN family. The next-generation LUMEN 4336W-HD advances the platform with a 100-micron imaging architecture, rugged IP68 construction, glass-free flexible detector substrate and optional SuperCapacitor power technology—eliminating the need for conventional lithium-ion detector batteries in the SuperCap configuration. Combined with Nexus DR acquisition software, the LUMEN HD platform is designed to deliver high-resolution imaging, simplified workflow and lower long-term ownership costs while building on Varex’s decades of detector engineering experience.
Lumen 100 Micron DR Systems
The LUMEN HD and HD Pro are advanced digital radiography detectors designed for reliability, versatility, and ease of use. They incorporate robust mechanical, power, and data configurations to meet demanding operational needs while minimizing costs and improving performance.
Key Features
Superior Durability:
-
- IP68-rated ingress protection and lightweight, drop-resistant housing materials.
- High point load protection for added resilience.
Optimized Power Options:
-
- Super-capacitor for fast charging and no removable parts.
- Removable battery for extended usage between charges.
- Tether-only operation for fixed installations.
Advanced Connectivity:
-
- Wi-Fi 6E with configurable modes (Client/Access Point/Hotspot).
- Seamless switching between tethered and wireless operation.
- Simple room-sharing key for flexible detector use across rooms and carts.
Ergonomic Design:
-
- Lightweight materials with an integrated 360° handle to reduce user fatigue.
- Simplified electronic design with capacitive power switches to minimize mechanical failures.
Cost Efficiency and Support:
-
- Modular design for lower deployment and ownership costs.
- Field-replaceable parts, common accessories, and a 5-year warranty.
- Advance replacement options for minimized downtime.
Nexus DR™ Image Acquisition Software
All Varex Imaging Medical DR systems are powered by Nexus DR software. Nexus DR™ is an advanced digital image acquisition software that drives XRpad and PaxScan DR solutions. It was designed to automate patient workflow, providing a trouble-free solution with advanced image processing algorithms for optimal image quality and excellent reliability.
